AKD2G Product Safety Guide | 1 English
1.4.2 Package Supplied
When a standard drive from the AKD2G series is delivered, the following items are included
in the drive package:
AKD2G
Printed copy of AKD
®
2G Product Safety Guide .
DVD with WorkBench setup software .
Panel safety label
Mating connectors are not included in the package of a standard drive.
Mating connectors are included when the drive is ordered with accessories (append “-A” to
the model number). With the accessories option all connectors to match the drive variant are
included, excepting SubD (Feedback 3), RJ25 (CAN bus) and RJ45 (service and fieldbus
networks).
Accessories Sold Separately
Accessories must be ordered separately if required.
EMC filters for mains supply voltage, categories C2 or C3.
External regen resistor.
Connector kits
Hybrid cable. Assembled hybrid motor cables are available for all regions.
Motor cable. Assembled motor cables are available for all regions.
Feedback cable. Assembled feedback cables are available for all regions.
SFA (Smart Feedback Adapter) .
SDB Module (Safe Dynamic Brake Module).
Ethernet service cable.
1.4.3 Ambient Conditions, Ventilation, and Mounting Position
Storage, Transport (➜ # 12)
Normal operation Environmental class 3K3 according to IEC 61800-2
Surrounding tem-
perature in operation
Internal regen resistor used:
0 to +40 °C under rated conditions
+40 to +60 °C with current derating 3 % per Kelvin
Internal regen resistor not used:
0 to +50 °C under rated conditions
+50 to +60 °C with current derating 2 % per Kelvin
Humidity in operation Relative humidity 5 to 85%, no condensation, IEC 61800-2 class
3K3
Site altitude Up to 1000 m above mean sea level (AMSL): no restriction
1,000 to 2,000 m AMSL: power derating 1.5%/100 m
Maximum altitude: 2000 m AMSL
Pollution level Pollution level 2 as per IEC 60664-1
Vibration Class 3M1 according to IEC 61800-2
Shock Class L according to IEC 61800-2
Drive protection IP 20 according to IEC 60529
Drive EMC immunity Increased immunity according to EN 61800-5-2
Mounting Vertical position, in a cabinet with protection of at least IP 54
Ventilation Built-in fan in all drive variants
The drive shuts down in case of excessively high temperature in
the control cabinet. Make sure sufficient forced ventilation is sup-
plied within the control cabinet.
16 Kollmorgen | kdn.kollmorgen.com | Beta, December 2018
