AKD2G Product Safety Guide | 9 Appendix
9.1 Electrical data
9.1.1 Single axis variants (S)
9.1.1.1 Mains supply data, 1 phase AC, type AKD2G-Sxx- (S)
Input data Units 6V03S 6V06S 6V12S
Rated supply voltage (L1/N) VAC 1 x 100 V to 240 V
Rated supply input frequency Hz 50 Hz to 60 Hz ±5%
Permitted switch on/off frequency 1/h 30
Rated input power @240 V kVA 1.2 2.38 2.64
Rated input current at 1 x 110 Vac A 5 9.9 11
Rated input current at 1 x 240 Vac A 5 9.9 11
Max. inrush current A 10
Rated DC bus link voltage VDC 310
9.1.1.2 Mains supply data, 3 phase AC, type AKD2G-Sxx- (S)
Input data Units 6V03S 6V06S 6V12S 7V03S 7V06S 7V12S
Rated supply voltage (L1/L2/L3) VAC 3 x 100 V to 240 V 3 x 200 V to 480 V
Rated supply input frequency Hz 50 Hz to 60 Hz ±5%
Permitted switch on/off frequency 1/h 30 30
Rated input power @240 V (*480V) kVA 1.2 2.38 2.64 2.24* 4.49* 7.65*
Rated input current at 3 x 110 Vac A 2.9 5.7 9.2 - - -
Rated input current at 3 x 240 Vac A 5 5.7 9.2 2.7 5.4 9.2
Rated input current at 3 x 400 Vac A - - - 2.7 5.4 9.2
Rated input current at 3 x 480 Vac A - - - 2.7 5.4 9.2
Max. inrush current A 10
Rated DC bus link voltage VDC 310 620
9.1.1.3 Auxiliary voltage input data, 24V DC, type AKD2G-Sxx- (S)
Input data Units 6V03S 6V06S 6V12S 7V03S 7V06S 7V12S
Aux. voltage supply (PELV) VDC 24 V (±10%, check voltage drop)
- control current without motor brake A 1
- control current with one motor brake A 3.5
- control current with two motor brakes A 6
54 Kollmorgen | kdn.kollmorgen.com | Beta, December 2018
