9.1.1.4 Output data, type AKD2G-Sxx- (S)
Units 6V03S 6V06S 6V12S 7V03S 7V06S 7V12S
Rheostatic energy dissipation
max. continuous power kW 1.5 3 6 12 12 12
internal regen resistor Ω 15 15 15 33 33 33
external regen resistor Ω 33 33 33 33 33 33
Continuous output current ( ± 3%)
at 1 x 110 Vac Arms 3 6 12 - - -
at 1 x 240 Vac Arms 3 6 12 - - -
at 3 x 110 Vac Arms 3 6 12 - - -
at 3 x 240 Vac Arms 3 6 12 3 6 12
at 3 x 400 Vac Arms - - - 3 6 12
at 3 x 480 Vac Arms - - - 3 6 12
Peak output current (for 5s, ± 3%) Arms 9 18 30 9 18 30
Continuous output power @ rated input current
at 1 x 110 Vac kVA tbd tbd tbd - - -
at 1 x 240 Vac kVA tbd tbd tbd - - -
at 3 x 110 Vac kVA tbd tbd tbd - - -
at 3 x 240 Vac kVA tbd tbd tbd tbd tbd tbd
at 3 x 400 Vac kVA - - - tbd tbd tbd
at 3 x 480 Vac kVA - - - tbd tbd tbd
Peak output power (for 1 s)
at 1 x 110 Vac kVA tbd tbd tbd - - -
at 1 x 240 Vac kVA tbd tbd tbd - - -
at 3 x 110 Vac kVA tbd tbd tbd - - -
at 3 x 240 Vac kVA tbd tbd tbd tbd tbd tbd
at 3 x 400 Vac kVA - - - tbd tbd tbd
at 3 x 480 Vac kVA - - - tbd tbd tbd
Emissions (low/high speed fan)
Noise emission dB(A) tbd tbd tbd tbd tbd tbd
Brake output
Voltage VDC 24 V (±10%)
Output current, minimum mA required 100 (fault detection)
Output current, maximum A 2.5
