9.1.2.4 Output data, type AKD2G-Sxx- (D)
Units 6V03D 6V06D 7V03D 7V06D
Rheostatic energy dissipation
max. continuous power kW 1.5 3 3 6
internal regen resistor Ω 15 15 33 33
external regen resistor Ω 33 33 33 33
Continuous output current ( ± 3%)
at 1 x 110 Vac Arms 2x3 2x6 - -
at 1 x 240 Vac Arms 2x3 2x6 - -
at 3 x 110 Vac Arms 2x3 2x6 - -
at 3 x 240 Vac Arms 2x3 2x6 2x3 2x6
at 3 x 400 Vac Arms - - 2x3 2x6
at 3 x 480 Vac Arms - - 2x3 2x6
Peak output current (for 5s, ± 3%) Arms 2x9 2x18 2x9 2x18
Continuous output power @ rated input current
at 1 x 110 Vac kVA tbd tbd - -
at 1 x 240 Vac kVA tbd tbd - -
at 3 x 110 Vac kVA tbd tbd - -
at 3 x 240 Vac kVA tbd tbd tbd tbd
at 3 x 400 Vac kVA - - tbd tbd
at 3 x 480 Vac kVA - - tbd tbd
Peak output power (for 1 s)
at 1 x 110 Vac kVA tbd tbd - -
at 1 x 240 Vac kVA tbd tbd - -
at 3 x 110 Vac kVA tbd tbd - -
at 3 x 240 Vac kVA tbd tbd tbd tbd
at 3 x 400 Vac kVA - - tbd tbd
at 3 x 480 Vac kVA - - tbd tbd
Emissions (low/high speed fan)
Noise emission dB(A) tbd tbd tbd tbd
Brake output
Voltage VDC 24 V (±10%)
Output current, minimum mA required 100 per brake (fault detection)
Output current, maximum A 2.5 per brake
