16
5 Game settings
I/O CHECK
Checking the controls
The original factory settings are displayed in green; the changed settings are
displayed in red.
·Press the 1P select button to select a mode to be modified. Press the 2P start
button to change the setting.
·After the setting has been changed, select “SAVE AND NEXT” and press the 1P
start button for entry.
“NOW SAVING” will appear, the modified settings will be saved, and the screen
returns to the main menu.
·If “EXIT” is selected after the modification of the settings, the following message
will appear.
“YOU DID NOT SAVE. DO YOU WANT TO SAVE? YES/NO” select “YES” or “NO”.
Press either the 2P start button or the select button to select “YES” or “NO”, and
press the 1P start button for entry.
If “YES” is selected, the new settings will be saved with “NOW SAVING” displayed
and the screen will return to the main menu.
If “NO” is selected, the message “NO MODIFICATION” will appear, the modified
settings will not be saved, but the main menu will show up again on the screen.
•If “FACTORY SETTINGS” is selected and the 1P start button is pressed, all the
setting of the mode will be returned to the factory setting.
MEMO
Mode for checking the performance of buttons and controls.
To return to the main menu screen, press the 2P start button while pressing the 1P
start button.
SCREEN CHECK
Mode for checking the screen display.
Adjust the focus, distortion and size of the image on the screen while watching the
crosshatch pattern. Use the monitor adjustment PCB (See page 48) to make
adjustments.
To return to the main menu screen, press the 1P start button.
Adjusting the screen distortion
•There are four footswitches for one panel. The following symbols are displayed
in addition to “ON”.
•L ... Left footswitch is ON. •R ... Right footswitch is ON. •U ... Upper footswitch is ON.
•D... Lower footswitch is ON. • - ... Footswitch is OFF
•Indication “ON” displayed without stepping on the foot panel may be due to entry
of sand or foreign matter in the foot panel. If that is the case, remove it according
to the description on page 45.
•If “ON” is still displayed even after the removal of sand or foreign matter,
immediately turn OFF the power switch, unplug the power cord and contact your
nearest dealer.
MEMO
5-3 Mode descriptions
