34
Halogen lamp
Lamp cover
Lamp covers(Red)
Lamp covers(Green)
Screws
Code No.: 0000053315
7-3 Replacing the spotlight lamp
How to replace the spoilight lamp
•Before replacing the halogen lamp, be sure to turn OFF the main power
switch and unplug the the power cord from the receptacle .
•The halogen lamp is still very hot immediately after the power switch is turned
off. Make sure that it is sufficiently cooled before replacement work.
•When replacing parts, be sure to use parts of the correct specifications.
Never use parts other than the specified ones.
•Strictly refrain from disassembly and repair of parts which are not indicated
in this manual, as well as settings and remodelling.
7 Maintenance
1 Be sure to turn OFF the main power switch and unplug the power cord from
the receptacle.
2 Remove the screws and detach the lamp covers.
3 Remove the halogen lamps.
4 Mount a new halogen lamp in the reverse of removal.
5 Attach the lamp covers as it was.
•Upper lamp covers: Red
•Lower lamp covers: Green
MEMO
