5 PREPARATIONS FOR DRIVE MODULE REPLACEMENT
5.1 Recording parameters from the V3F16L drive module
Write following drive parameters down to the site survey list before switching OFF the power from the
drive module.
You need this information later on when commissioning new drive module.
NOTE! It is recommended to check load weighing device operation. Purpose of this step is to verify
operation of the load weight device before continuing drive module replacement.
5.2 Checking LCE software version
The LCE software must be updated, if the LCE version is older than 5.1.0 (18.01.2002).
Stand-by mode and brake test features require LCE version 6.7.18 or newer.
Reference list for parameter numbers of the replaced
drive module
V3F16 KDL16 Value
Machine parameters 6_1 6_60
Nominal speed of the elevator (determines also acceleration
and jerk)
6_2 6_3
Elevator load 6_3 6_4
Roping 6_4 6_7
Acceleration (manually changeable, determines also jerk) 6_20 6_2
Step Action Illustration/Note
1 Check the existing LCE software version on
user interface in the MAP.
Action Display
Push MENU button until number 4 shows on
the MENU display.
Verify selection by pushing ACCEPT button.
4 _ _ __
Push Arrow buttons until number 10 shows
on the MENU display.
Verify selection by pushing ACCEPT button.
4 _10 _ __
The display shows drawing number and
version of the LCE software.
For example 813140 6.0.4
2 If the software version is old, update the old
software according to
APPENDIX A.
