AS-11.65.037
7 (40) (A) 2009-10-16
KDL16
Maintenance Instruction
© 2009 KONE Corporation
All rights reserved.
Disclosure prohibited
1.6 V3F16L rev. 1.x drive module
1. Brake cable connector, XBR3
2. LCE cable connector, XS3
3. Motor cable connector, U-V-W
4. Supply cable connector, T1-T2-T3
5. Cable connector for LWD and motor current
signals, XW1
6. MAP tachometer connector, XLG1
7. Tachometer cable connector, XG1
8. LCECPU cable connector, XL1
9. Motor thermistor connector, XT1
10. Braking resistor cable connector, XBRE2
11. Cover plate
12. Holding wire for cover plate
13. Slots for cable bushings
