10 FINALIZING DRIVE MODULE REPLACEMENT
If machine room elevator start the finalizing from section 10.2.
If KONE MonoSpace
®
type elevator start the finalizing from section 10.1. If the elevator is equipped
with DOM or LPT safety devices, and the landing door has been opened with emergency release key,
the system must reset before the elevator can drive on normal.
10.1 Safety measures (KONE MonoSpace
®
type elevators)
10.2 Finalizing the replacement
Step Action Illustration/Note
1 Switch the elevator on inspection. Follow the safety practises according to
elevator specific MBM-2 manual.
2 Push down the stop button on inspection
drive unit.
Reset the LPT / DOM, if applicable, by
switching reset key switch.
3 Switch OFF the RDF.
4 Go to the car roof.
5 Drive the car downwards on inspection.
Position the car with access to the SEP.
Step Action Illustration/Note
1 Connect the battery back-up cable to the
LCECPU (XM14) in SEP/ReCab panel
(MRL elevators) or in control cabinet (MR
elevators).
2 Drive the car back to the topmost landing
level on inspection.
Reset the LPT / DOM, if applicable.
Only MRL elevator.
