9 PARAMETER SETTINGS
9.1 Setting drive parameters
All the steps in the following table must always be carried out in following order.
Step Action Illustration/Note
1 Check that Document identification (6_0)
parameter matches the ID on parameter list
972483D01.
Set the elevator dependent parameters:
2 Parameter lock (6_95) parameter to 0.
3 Default parameters (6_98) parameter to 1. Wait at least for 10 seconds.
4 Motor type (6_60) parameter
Refer to section 5.1.
See also table below.
Setting Motor type (6_60) parameter turns
parameters 6_4, 6_6, 6_7, 6_10, 6_11,
6_25, 6_30, 6_61, 6_64, 6_65, 6_67,
6_80..84, 6_86, 6_87 value to default
settings for that type of motor.
5 Acceleration (6_2) parameter Refer to section 5.1.
6 Nominal speed (6_3) parameter
7 Elevator load (6_4) parameter
8 Roping (6_7) parameter
9 Save (6_99) parameter to 1. Value is returned automatically to 0.
10 Switch the power OFF.
Wait at least for 15 seconds.
This actions ensures that parameters are
stored correctly.
11 Switch the power ON. Ensure that the RDF is switched ON.
12 Check that the Motor type (6_60)
parameter is set to the correct value.
Value Type 6_6 6_64 6_80 6_81 6_82 6_83 6_84 6_86 6_87
KONE MonoSpace
®
elevators:
5.20 MX05/10 340 14452 208 9.0 13.1 112.3 2.8 3.50 8.8
5.22 MX05/16 340 14452 210 14.0 21.0 179.8 4.5 1.45 5.6
6.20 MX06/05, MX06/10 400 17067 208 11.2 12.7 96.0 3.7 2.47 6.8
6.21 MX06/16 400 17067 226 16.5 20.4 153.0 5.9 1.17 5.0
10.20 MX10/05, MX10/10 480 19819 217 16.5 13.3 79.6 5.7 1.55 4.9
KONE ReGenerate™ elevators:
6.20 MX06/05, MX06/10 400 17067 208 11.2 12.7 96.0 3.7 2.47 6.8
6.21 MX06/16 400 17067 226 16.5 20.4 153.0 5.9 1.17 5.0
10.20 MX10/05, MX10/10 480 19819 217 16.5 13.3 79.6 5.7 1.55 4.9
10.28 MX10/08 480 19819 139 12.9 6.6 39.8 2.9 2.00 3.1
