Konica Minolta bizhub 4000P Service Manual

bizhub 4700P/bizhub 4000P Service Manual
- 244 -
4. Remove the two screws (A) securing the rear cover.
5. Press the two latches to release the rear cover.
6.7.3 Narrow media/bin full sensor removal
1. Remove the right cover. See Right cover removal.
2. Remove the left cover. See Left cover removal.
3. Remove the rear door and cover. See Rear door and cover removal.
4. Remove the top cover. See Top cover removal.
5. Disconnect the cable JNRW1 from the controller board.
6. Remove the six screws (A) securing the sensor and upper exit guide to the redrive assembly.

Konica Minolta bizhub 4000P Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 100, 000 pages
Standard Output Capacity	150 sheets
Memory	256 MB
Supported Operating Systems	Windows, Mac OS, Linux
Duplex Printing	Automatic
Connectivity	USB 2.0, Ethernet
PDL	PCL 6, PostScript 3, XPS
Processor Speed	1.2 GHz
