Explanation Section
When the optional 4-Probe Expansion Board CA-B15 is used
Break-
down
No.
Action
Symptom
Check Point
Ref.
13
Probes P2 to P5
cannot be se-
lected.
(cannot be dis-
played in the LCD
display section)
Is the 4-Probe Expansion Board installed
correctly?
Install it correctly. 27
Are the measuring probes connected to the
probe connectors [P2] to [P5] properly?
Connect necessary number of probes to the
probe connectors properly.
26
27
14
Probe cannot be
changed.
(cannot be dis-
played in the LCD
display section)
Do you want to select LED Universal Mea-
suring ø27 Probe(CA-PU32/35) or LED
Universal Measuring ø10 Probe(CA-
PSU32/35) when the measurement mode
is Flicker Mode?
Select the measurement mode other than
Flicker Mode.
43
