Main Body
<Front>
A
POWER switch .........................................• Used to turn ON and OFF the power to the instrument. (Page 29)
B
Digital display section ..............................• Displays the measured values.
C
Analog display section .............................. • Displays the difference (%) between the measured value and the
target color or the difference (%) between measured values.
Measured values are displayed in the case of icker mode.
• The range for each dot can be set between 0.1 and 99%. (Page 69)
D
Measurement mode indications ................• Displays the measurement mode in which the measured values
are displayed. (Page 40)
• The table below shows the relationship between measurement
modes and data displayed in the digital display section 2 and
analog display section 3.
Measurement mode
2
Digital display
3
Analog display
xyLv mode x, y, Lv
∆
x,
∆
y,
∆
Lv
T
∆
uvLv mode T,
∆
uv, Lv
∆
x,
∆
y,
∆
Lv
Analyzer mode (G reference) R, B, G R/G, B/G,
∆
G
Analyzer mode (R reference) R, B, G
∆
R, B/G, G/R
u'v'Lv mode u', v', Lv
∆
x,
∆
y,
∆
Lv
Flicker mode** Flicker value Flicker value
XYZ mode XYZ
∆
x,
∆
y,
∆
Lv
**Only when LED Flicker Measuring ø27 Probe or LED Flicker Measuring ø10 Probe is connected.
E
LCD display ..............................................• Displays the memory channel, probe no., ID name, warning and
settings.
F
HOLD LED...............................................• Lights up during hold.
G
REMOTE LED .........................................• Lights up when the instrument is ready for communication with
the PC via RS-232C or USB interface.
H
Key panel ..................................................• Used to select/set probe no., SYNC mode, measurement speed,
analog display range and ID name, as well as entering values.
(Page 17)
I
Tilt stand
<Rear>
J
Probe connector [P1] ................................• Used to connect a measuring probe. (Page 26)
K
USB connector ..........................................• USB interface for communication with a PC. (Page 88)
L
RS-232C connector ................................... • RS-232C compatible interface for communication with a PC.
(Page 86)
M
Vertical synchronizing signal ................... • Input the display’s vertical synchronizing signal into this terminal
input terminal when performing measurement in EXT SYNC mode. (Page 28)
SYNC: Terminal shall tread as class 3 accordance with IEC
610101-1 Annex-H.
N
AC power connector
.................................• Connect the AC power cord to this connector to supply power to
the instrument. (Page 28)
• The rating is 100-240V , 50-60 Hz, 50VA.
O
4-Probe Expansion Board slot ..................• Used to install the optional 4-Probe Expansion Board (CA-B15).
(Page 27)
