Replacing Consumables
151
10 Prepare a new transfer belt unit.
" Be careful not to touch
the surface of the belt.
" Do not remove the blue
lever.
11 Remove all packing tape from
the new transfer belt unit.
12 Remove the protective cover
from the new transfer belt unit.
13 Insert the new transfer belt unit
along the rails.
To Next Page
