Parameters of each mode
46
VDA1
VDA EG
Specifies the envelope of the VDA 1 EG. Drag the points of
the graphic envelope. (☞ “Graphical envelopes” on page 9)
☞ M1 owner’s manual PDF, page 28 “F4-1: VDA1 EG”
VEL SENS
☞ M1 owner’s manual PDF, page 28 “F4-2: VDA1 VEL
SENS”
EG INT......................................................[–99…+00…+99]
EG TIME................................................................. [00…99]
☞ “OSC1” on page 38.
TIME POLARITY A, D, S, R .........................................[+, x, –]
☞ “TIME POLARITY A, D, S, R” on page 43.
KBD TRK
☞ M1 owner’s manual PDF, page 28 “F4-3: VDA1 KBD
TRK”
AMPLITUDE ...............................................[–99…+00…+99]
Specifies the degree to which keyboard tracking will affect
the depth of volume change.
EG TIME .................................................................[00…99]
Specifies the degree to which keyboard tracking will affect
the speed of the VDA EG.
TIME POLARITY A, D, S, R .........................................[+, x, –]
These specify how velocity will affect the VDA 1 EG’s A
(Attack Time), D (Decay Time), S (Slope Time), and R
(Release Time).
CENTER KEY......................................................... [C-1…G9]
Specifies the key (note) that will be used as the center for
keyboard tracking.
You can also enter these values by double click, play-
ing a note on the external MIDI keyboard, and press
the [Enter] key of your computer.
VDA MG
The VDA MG applies modulation to the VDA. These param-
eters are the same as for the PITCH MG of the OSC page.
☞ “PITCH MG” on page 40
VDA 2
These parameters are the same as for VDA 1.
