Performance edit Quick parameter list
29
Quick parameter list
The tree diagram shown on the left shows how the
performance edit parameters (quick parameters) are
organized. These parameters are explained below.
Common
Rename
Specifies the name of the performance (p. 26).
SplitPoint [C#2...C7]
Specifies the split point. This value is effective only
when split is on.
Tip: You can set this from the front panel. Press the
LOWER button and UPPER button. Then press the key
that you want to specify as the split point. The key you
pressed will be the lowest key of the upper region.
Scale:
Specifies the scale used by the performance. Separately
from this setting, you can make the “Scale” parameter
of the program take priority for each timbre
( “UsePrgScl (Use Prog Scale),” p. 31).
Type [EqualTemp...UsrOct 03]
Selects the scale ( “Type,” PG p.5).
EqualTemp (Equal Temperament)
PureMajor (Pure Major)
PureMinor (Pure Minor)
Arabic
Pythagras (Pythagoras)
Werkmeist (Werkmeister): Werkmeister III
Kirnbrger (Kirnberger): Kirnberger III
Slendro
Pelog
Stretch: This tuning is used for acoustic pianos.
UsrAllNte (User All Notes Scale): (PG p.75).
UsrOct (User Octave Scale) 00...03: (PG p.75).
Note: User All Notes Scale and User Octave Scale
can be specified using the Global mode User Scale
settings in PS60 Editor/Plug-In Editor.
Note: Use Equal Temperament for the preload
programs 13:SoloStretch Grand –15:SoloStretch
Classic.
Key (Scale Key) [C…B]
Selects the key of the specified scale.
This setting does not apply to the Equal
Temperament, Stretch, and User All Notes scales.
Random [0…7]
This parameter creates random variations in pitch
for each note.
Common Rename
SplitPoint
Scale Type
Key
Ramdom
Tempo
Main Timbres A.Piano Program Select
Volume
Pan(Pre)
Pan(Post)
Send1(Mod)
Send2(Rev)
Status
MIDI Ch.
Bank MSB*
Bank LSB*
OSC Select
OSC Mode
Portamento
Octave
Transpose
Detune
Bend Range
UserPrgScl
Filter/Amp Cuto
Resonance
Flt EG Int
AmlVel Int
Firter/ Attack
Amp EG Decay
Sustain
Release
MIDI Filter Damper
Foot SW
Foot Pedal
JS X as AMS
JS+Y
JS-Y
ProgChange
Porta. SW
Ribbon#16
Other CC#
E.Piano
Organ
Strings
Brass
Synth
Sub Timbres
MFX1 (Mod.) Eect Rate(Hz)
Depth
Feedback
On/O
Return1
Chain
ChainLevel
MFX2 (Rvb/Dly) Eect Time(sec)
Level
Feedback
On/O
Return2
EQ Trim
BassGain
Bass
BassFreq
Bass Q
Mid Gain
Mid Freq
Treble G
Treble
Treble F
Treble Q
Master Vol
Comand Initialize
Copy MFX/EQ
Type
Type
Performance Edit
(Same as A.Piano)
(Same as A.Piano)
(Same as A.Piano)
(Same as A.Piano)
(Same as A.Piano) * There is no “Pan(Post)”
(*Status:EX2)
(Same as Main Timbres.)

Korg PS60 Specifications

General

Type	Performance Synthesizer
Synthesis Type	Sample-based synthesis
Velocity Sensitivity	Yes
Aftertouch	No
Arpeggiator	Yes
Sequencer	No
MIDI	In, Out, Thru
Power Supply	DC 9V
Keyboard	61 keys
Sound Engine	EDS-i
Effects	2 Master effects
Controllers	Pitch bend, modulation wheel
Outputs	2 x 1/4" (L/R)
USB	Type B x 1
Sound Generator	EDS-i
Preset Programs	440 programs
Polyphony	120 voices (120 Oscillators)
Inputs	1 x 1/4" (damper)
