Reference Guide
109
Reference Guide
Multi Setup
Parameters
3
*
B Level, Pan, Send
This page lets you adjust the volume level and output settings for each Track.
Level:
Adjusts the volume level setting for each Track.
Panpot:
Adjusts the A and B output balance of each Track.
Setting OFF outputs no signal at A or B. Setting A15 outputs signal only from A; setting B15
outputs signal only from B; and setting CNT (Center) outputs the same signal level from A and B.
With the PRG setting, the panpot setting of the Program selected for the Track is used. (You can
specify the panpot setting for each oscillator in Program Edit mode.) With settings other than
“PRG”, both Oscillator 1 and 2 of the Program use the same panpot setting.
If you have already selected a Program using a Drum Kit (OSC mode set to DRUMS) and you
select “PRG” here, the panpot setting for each Instrument of the Drum kit will be used. If you set
this parameter to A15 – B15, the panpot setting of each Instrument is ignored, and the parameter
setting here becomes effective.
You can control the panpot setting of each Track by sending MIDI Pan Change data [Bn, 0A, xx]
(Controller #10). (With a setting of OFF or PRG, the MIDI Pan Change data is ignored.) When
you specify [00] for [xx], the parameter value is set to A15, and when you specify 127 [7F] for
[xx], the parameter value is set to B15. You need to specify 64 [40] for the CNT setting.
Refer to “MIDI Panpot, Send Data” on page 173 for MIDI data corresponding to the panpot
settings.
•
When the power is turned on, when 23A SET TO GM is being executed, or when a GM ON
message is received, Track 10 will use the PRG setting, and other Tracks will use the CNT
setting.
Send:
Sets the C and D output level of each Track.
Setting “P (Program)” selects the Send setting of the Program selected for the Track. (You can set
Send for each oscillator in Program Edit mode.) Specifying a value other than “P” sets the output
of Oscillator 1 and 2 to the same level.
MIDI Bank Select
X5DR Bank
(MSB) (LSB)
00
38
3E
3F
00
**
**
**
Bank A
Bank G
Bank G
(Timbre OFF)
(01–128)
(129–136)
**
: any number
LCD Parameter Range Description
*
B
Level (Lev)
Panpot (Pan)
Send C (Sen)
Send D (Sen)
0–127
OFF, A15–CNT–B15, PRG
0–9, P
0–9, P
Volume level
Panpot (between A and B) setting
Level C setting
Level D setting
*
B
00B Lev Pan Senø
T01 100 CNT 2:2
The resultant volume level for each track is obtained by
multiplying the MIDI Volume data [Bn, 07, xx] (Controller #7),
MIDI Expression data [Bn, 0B, xx] (Controller #11), and the
value displayed on the screen. The level parameter value is not
affected by MIDI Control Change messages.
MIDI Volume data (this is not a level parameter) is set to 100
when Multi mode is entered, when 23A SET TO GM is being
executed, or when a GM ON message is received. (In other
mode, Volume data is set to 127.)
Level
MIDI Volume
MIDI Expression
Volume
