Reference Guide
111
Reference Guide
Multi Setup
Parameters
3
*
D MIDI Filter
This page determines whether or not each Track will receive the MIDI Program Change and
whether or not Damper message, After Touch message, and Control effect are applied.
Program Change Filter:
Determines whether or not each Track receives the MIDI Program
Change messages.
EN:
Tracks with the EN (Enable) setting receive the Program Change messages and switch the
Programs. Set the overall X5DR Program Change Filter on 2C MIDI FILTER PRG in Global
mode. (see “2C Program Change Filter” on page 152.)
Damper Pedal Filter:
Determines whether or not each Track receives the Damper Pedal On/Off
messages.
EN:
The Damper Pedal messages are received on the Track for which “EN (Enable)” is selected.
DI:
The Damper Pedal messages are not received on the Tracks for which “DI (Disable)” is
selected.
After Touch Filter:
Determines whether or not each Track receives the After Touch messages.
EN:
After Touch messages are received on the Track for which “EN (Enable)” is selected.
DI:
After Touch messages are not applied to the Tracks for which “DI (Disable)” is selected.
Control Change Filter:
Determines whether or not the controllers (e.g., pitch bend, pitch
modulation, or the Volume) are received on each Track.
EN:
The Controller messages are received on the Track for which “EN (Enable)” is selected.
DI:
The Controller messages are ignored on the Tracks for which “DI (Disable)” is selected.
•
These parameters for all the tracks are set to “EN”, when you turn the power on to the X5DR,
when 23A SET TO GM is executed, or the X5DR receives the GM on message.
LCD Parameter Range Description
*
D
Program Change
Filter (Pf)
DI: Disable
EN: Enable
Program Change message is ignored.
Program Change message is received.
Damper Pedal Filter
(Df)
DI: Disable
EN: Enable
Damper Pedal message is ignored.
Damper Pedal is received.
After Touch Filter (Af)
DI: Disable
EN: Enable
After Touch message is ignored.
After Touch is received.
Control Change Filter
(Cf)
DI: Disable
EN: Enable
MIDI Controllers are ignored.
MIDI Controllers are received.
Note:
If the Global mode MIDI Program Change Filter 1 is set to “DIS”, the Program Change
messages are completely disabled. Furthermore, if you set it to ENA or PRG, Bank Select and
Program Change messages will select Bank and Program. If you set it to “NUM”, only the
Program is changed. (see “2C Program Change Filter on page 152)
*
D
00D Pf Df Af Cfø
T01 EN EN DI EN
To Next Page
