1. Program Parameters
Functions in Program Mode
Key operations:
Selecting a page . . . . . . . . . . . . . . [PAGE+] key, [PAGE–] key
Selecting a parameter . . . . . . . . . . [ √
] key, [®] key
Setting a parameter value . . . . . . . [ ▲
] key, [ ▼ ] key
Page numbers shown in the upper left corner of the screens in Single or Drums mode are different
from those in Double mode. This manual uses the page examples in Double mode.
• For information on Effects, See “Effect Parameters” on page 115.
Page
Function Parameters
SINGLE,
DRUMS
DOUBLE
0A–0B 0A–0B
OSC Mode
Oscillator mode
Number of voices to sound, and Hold settings
Assign/Hold
1A–1D 1A–1D
OSC1
Multi Sound (Drum Kit)
Level/Octave
Oscillator 1 waveform
Level, Octave Double mode only
Depth of the pitch change over time, output destination
EG Intensity/Pan/Send
— 2A–2F OSC2
Multi Sound
Level/Octave
EG Intensity/Pan/Send
Interval/Detune
Delay
Refer to the OSC1 parameters.
Interval (by semitone) and detune (by cent) relative to OSC1
Delay in sounding OSC2 relative to OSC1
2A–2C 3A–3C Pitch EG Adjusts changes in pitch over time
3A–3E 4A–4E VDF1
Cutoff
EG
Color
VDF1 cutoff frequency (Controls brilliance of tone)
Specifies changes in cutoff frequency over time.
Color (feedback effect)
4A–4E 5A–5E VDF1
Velocity Sense
Keyboard Tracking
How key velocity affects VDF1 EG cutoff frequency and time
How key position affects VDF1 EG cutoff frequency and time
— 6A–6E VDF2
Cutoff
EG
Color
Refer to the VDF1 parameters.
— 7A–7E VDF2
Velocity Sense
Keyboard Tracking
5A–5C 8A–8C VDA1 EG Change in VDA1 level over time
6A–6E 9A–9E VDA1
Velocity Sense
Keyboard Tracking
How key velocity affects VDA1 EG cutoff frequency and time
How key position affects VDA1 EG cutoff frequency and time
— 10A–10C VDA2 EG
Refer to VDA1 parameters.
— 11A–11E VDA2
Velocity Sense
Keyboard Tracking
7A–7E 12A–12E Pitch1 MG Oscillator 1 pitch MG (vibrato)
— 13A–13E Pitch2 MG Oscillator 2 pitch MG (vibrato)
8A–8C 14A–14C VDF MG VDF modulation (wah-wah effect)
9A–9D 15A–15D
After Touch Control
Joy Stick Control
After Touch control
Joystick controll
10A–15A 16A–20A Effect Effect settings
16A–16B 22A–22B
Program Write Rename
Program
Writes a Program
Renames a Program
