Reference Guide
112
*
E Key Window Top & Bottom
These parameters allow you to set the top note and bottom note for each Track.
A key window is the range of keys (notes) that you can use to play a Track. Used in conjunction
with the Key Window Bottom parameters, you can assign sections of the keyboard to specific
Tracks. For example, you could designate the bottom half of the keyboard to a bass Track, and the
top half to a piano Track (page 102).
You can not set the top key to lower than the bottom key. Otherwise, the bottom key will be set to
the same value as the top key. The same thing applies to the bottom Key.
•
When the power is turned on to the X5DR, when 23A SET TO GM is being executed, or when
a GM System ON message is received, the top key of each track is set to G9, and the bottom
key of each track is set to C-1.
*
F Velocity Window Top & Bottom
These parameters allow you to set the maximum and minimum velocity for each Track’s velocity
window.
•
When the power is turned on to the X5DR, when 23A SET TO GM is being executed, or when
a GM System ON message is received, the maximum velocity of each track is set to 127, and
the minimum velocity is set to 1.
LCD Parameter Range Description
*
E
Key Window Top
(KWTop)
C–1~G9 Specifies the top note for each Track’s key window.
Key Window Bottom
(KWBtm)
C–1~G9 Specifies the bottom note for each Track’s key window.
LCD Parameter Range Description
*
F
Velocity Window Top
(VWTop)
1~127 Specifies the maximum velocity for each Track.
Velocity Window
Bottom (VWBtm)
1~127 Specifies the minimum velocity for each Track.
*
E
00E KWTop KWBtmø
T01 G9 C-1
*
F
00F VWTop VWBtmø
T01 127 001
