Reference Guide
113
Reference Guide
Multi Setup
Parameters
3
*
G MIDI Channel
These parameters allow you to set the MIDI Channel that each Track uses to receive MIDI data.
If you want to play a Track from the keyboard (such as the X3), you should set each Track’s MIDI
Channel on the X5DR so that it matches the X3’s MIDI transmit channel. If you are using a
sequencer, set each Track’s MIDI Channel so that it matches the corresponding sequencer track’s
MIDI Channel.
If the selected MIDI Channel is the same as the Global MIDI Channel, a G will appear next to the
selected channel number.
•
When the power is turned on to the X5DR, when 23A SET TO GM is being executed, or when
a GM System ON message is received, the MIDI Channel of Tracks 1–16 is set to 1–16.
16A – 21A Effect
Effects are explained in “Effect Parameters” on page 115.
The individual effect settings of each Program are ignored, and these settings are used.
If you want to use a Program’s or a Combination’s effect settings, use the 21A COPY EFF
function to copy effects. (See “21A Copy Effects” on page 119.)
Track parameters Pan A, Pan B, Send C, and Send D are used to control the level of the Tracks
sent to the effects in Multi mode.
Effects can be controlled via MIDI on the Global MIDI Channel. You can control the level of each
Track to the effects using the Track parameters Pan A, Pan B, Send C, and Send D.
•
When the power is turned on to the X5DR, when 23A SET TO GM is being executed, or when
a GM System ON message is received, Effect 1 selects Hall, Effect 2 selects Chorus1,
Placement selects Parallel3, and the effect return level is set to 4.
22A Copy from Combination
This function allows you to copy Combination Timbre settings to Tracks 1 to 8 or Tracks 9 to 16.
The following parameter settings are copied: Program, Volume, Transpose, Detune, Pan, Send C,
Send D, Key Window, Velocity Window, MIDI Channel, and Filters (Program Change, Damper
Pedal, After Touch, Control Change).
The Combination’s effect settings are not copied. Use 21A Copy Effect to copy the effect settings.
(see page 119.)
For *C Bend Range parameters that are not included in Combinations, the value of Program’s
Joystick Pitch Bend Range (15D in Program Edit mode) of each Track will be copied.
LCD Parameter Range Description
*
G MIDI Channel 1~16
Sets the MIDI Channel that each Track uses to receive MIDI
data.
LCD Parameter Range Description
22A
Source Combination 00 ~ 99 Selects the Combination to copy.
Destination Tracks 1–8, 9–16 Selects the eight destination tracks.
OK to Copy from
Combination
OK? Executes Combination copy.
00G MIDI Ch
T01 1G
*
G
ø
22A COPY COMBI
COMB 00 1-8 OK?
22A
To Next Page
