Basic Guide
71
About
MIDI
5
Basic Guide
Effect 2 On/Off (CTRL#94)
Effect 2 On/Off messages [BnH,5EH,vv] (Controller #94, vv:Value) are used to turn Effect 2 On
and Off. When “vv” is 0, Effect 2 is turned Off, and when “vv” is any value between 1 and 127,
Effect 2 is turned On.
•
These messages are received only on the Global MIDI Channel.
Data Increment/Decrement (CTRL#96/97)
Data Increment [BnH,60H,00H] (Controller #96 for 0) and Data Decrement [BnH,61H,00H]
(Controller #97 for 0) messages are used to increase/decrease the parameter value specified by the
RPN by steps of one. When the X5DR receives a Data Increment message, the parameter value is
increased by one, and receiving a Data Decrement message decreases the value by one. Refer to
the following RPN explanation for information on how to use these messages.
RPN LSB/MSB (CTRL#100/101)
RPN messages [BnH,64H,rr] (Controller #100, rr: Lower digits of the value), [BnH,65H,mm]
(Controller #101, mm: Upper digits of the value) are used to select parameters. RPN is an acronym
for Registered Parameter Number, which allows you to control the common parameters on various
MIDI devices. Select a parameter using RPN messages, then set the parameter value using Data
Entry Increment/Decrement messages.
The Pitch Bend Range, Fine Tune, and Coarse Tune parameters on the X5DR respond to these
messages.
● To set the Pitch Bend Range parameter, send the
RPN messages [BnH,65H,00H] (Controller #101
set to 00) and [BnH,64H,00H] (Controller #100 set
to 00), followed by the Data Entry messages
[BnH,06H,vv] (Controller #06, vv:Bend range) and
[BnH,26H,00H] (Controller #38 set to 00). “vv”
specifies the bend range in steps of one semitone.
When “vv” is 00, the bend range is “0”, and when
Controller No.
06
00
01
12
38
00
00
0
Pitch Bend (semitone)
c
c
0
+ 1
+12
c
“vv” is 12, the bend range is one octave (12 semitones). These messages are received only in Multi
mode for the pitch bend range adjustment.
● To set the Fine Tune parameter, send the RPN messages [BnH,65H,00H] (Controller #101 set to
00) and [BnH,64H,01H] (Controller #100 set to 01), followed by the Data Entry messages
[BnH,06H,nn] (Controller #06, nn:Upper digits of the value) and [BnH,26H,nn] (Controller #38,
vv:Lower digits of the value). “vv” and “nn” specify
the fine tune value, and tuning will be changed as
shown in the table.
These messages allow you to adjust detune values
for each Track in Multi mode, and master tune value
in Global mode.
● To set the Coarse Tune parameter, send the RPN
messages [BnH,65H,00H] (Controller #101 set to
00) and [BnH,64H,02H] (Controller #100 set to 02),
followed by the Data Entry messages [BnH,06H,vv]
(Controller #06, vv:Value) and [BnH,26H,00H]
(Controller #38 set to 00). “vv” specifies the coarse
tune value, and transposition will be changed as
shown in the next table.
These messages are received only in Multi mode to
adjust transposition.
Controller No.
06
32
48
64
96
38 Fine Tune (cent)
ccc
00
00
00
00
ccc
–50
–25
0
+50
ccc
Controller No.
06
40
52
64
88
38 Coares Tune (semitone)
ccc
00
00
00
00
ccc
–24
–12
0
+24
ccc
