11 Menu description
11.5 Menu 3: Output settings
Menu item Description
3.09Setting Scale
pulse output1
The scale of the pulse output is used to set the pulse significance. Since the pulse values can also be
output in packets, the manufacturer recommends using the pulse output only for total values.
Select the scale so that the limit frequency of 250/125Hz is not exceeded.
0
Pulse output is switched off. No pulses are output anymore.
Note:
After the setting has been changed, the electronic unit has to be restarted.
3.10Setting Allocation
pulse output2
A total value can be assigned freely to the Pulse output2.
T
Total consumption A-B or A+B
TA
Total flow flowmeterA
TB
Total flow flowmeterB
Requirement:
3.07Setting Function pulse output Set to Independent .
Note:
After the setting has been changed, the electronic unit has to be restarted.
3.11Setting Scale
pulse output2
The scale of the pulse output is used to set the pulse significance. Since the pulse values can also be
output in packets, the manufacturer recommends using the pulse output only for total values.
Select the scale so that the limit frequency of 250/125Hz is not exceeded.
0
Pulse output is switched off. No pulses are output anymore.
Requirement:
3.07Setting Function pulse output Set to Independent .
Note:
After the setting has been changed, the electronic unit has to be restarted.
3.12Setting Pulse
output pulse width
setting
Increasing the pulse width always involves a reduction in the maximum output frequency (e.g. pulse
width 200 ms – maximum frequency 2.5Hz).
Note:
After the setting has been changed, the electronic unit has to be restarted.
