5-112 BA 35203_04 * 3.0 * 35203_04_05_Bedienung.fm
5 Operation
Unhitching the trailer
In order to avoid dirt accumulation in the ball hitch lugs, close them again
after uncoupling the trailer!
► Press lever F down until the coupling pin engages in the ball hitch.
1. Park the machine and the trailer on level ground.
2. Apply parking brake.
3. Stop the engine.
4. Switch off the starter and remove the starting key.
5. Secure the trailer with wheel chocks.
6. Apply the trailer parking brake.
7. Disconnect the electric D and hydraulic E connections between the
machine and the trailer.
8. Close the flat connector plugs on the machine and the trailer with the
protective caps provided.
9. Disconnect trailer. To do this, push lever C of the ball hitch upward until
the coupling pin locks into place.
Closing the coupling by hand (for example for a tow cable)
Accident hazard due to coupling pin snapping down!
Can cause injury.
► Do not touch the coupling pin with your hands.
1. Carefully press lever F down until the coupling pin engages in the ball
hitch.
