BA 35203_04 * 3.0 * 35203_04_06_Transport.fm 6-9
Transport 6
Tying down the machine
Tie down as follows
1. Secure all tyres of the machine with chocks in front of and behind each
wheel.
2. Firmly tie down the machine at the eye hooks – see symbol A on the
front and rear machine frame – see chapter 3 “Machine overview” on
page 3-1 – with ratchet straps or chains of sufficient size onto the
platform.
➥ Do not place cables, belts, etc. over sharp-edged objects.
➥ Use only tested ropes, belts, hooks, shackles (with screw and
socket pins with lockable frames) for tying down the machine.
3. Before transporting the machine through heavy rain, close the outlets
of the exhaust silencer with a simple cap or suitable adhesive tape.
4. Ensure that the operator of the transport vehicle knows the overall
height, width and weight (including the loaded machine) before driving
off, and the legal transport regulations of the country or countries in
which transport will take place!
