Kramer VW-16 User Manual

Kramer Electronics Ltd.
VW-16 – Technical Specifications
36
Technical Specifications
Inputs
HDMI
4 x HDMI 2.0
Outputs
HMDI
16 x HDMI 2.0
Audio Output
Stereo unbalanced on a 3-pin terminal block
Image Processing
Input Resolutions
4096 x 2160p (60Hz, 50Hz, 24Hz), 3840 x
2160p (60Hz, 50Hz, 30Hz, 25Hz, 24Hz), 2560
x 1080p (60Hz), 1920 x 1080p (60Hz, 50Hz,
30Hz, 25Hz, 24Hz), 1920 x 1080i (60Hz,
50Hz), 1280 x 720p (60Hz), 720 x 480p (60Hz,
50Hz), 720 x 576p (50Hz), 640 x 480p (60Hz,
50Hz)
Input & Output Chroma
Sampling
4:4:4
Output Color Depth
24 bpp
Video Bandwidth
Up to 18 Gbps
Output Resolutions
4096 x 2160p (60Hz ,50Hz), 3840 x 2160p
(60Hz, 50Hz, 30Hz), 2048 x 2048p (57Hz),
1920 x 1200p (60Hz), 1920 x 1080p (60Hz,
50Hz, 30Hz), 1600 x 1200p (60Hz), 1280 x
720p (60Hz, 30Hz)
HDMI Compliance
HDMI 1.4 And HDMI 2.0
HDCP Compliance
HDCP 1.4 And HDCP 2.2
Controls
RS-232 / Telnet
1 x D9 female connector
RS-485 / RS-422
5-pole terminal block
Ethernet Port
1 x RJ45 /
Web Interface
Embedded Web UI
Firmware
Possible: Upgrade
1 x USB 2.0
Power
Dual (Redundant) Power
Supplies
Built-in power modules 100–240 VAC / 50/60
Hz
Power Consumption
300W
Heat Dissipation
260W (885BTU/hr)
Noise Level
Ambient Noise
For rack max = 46db, for desktop max = 40db
Environmental
Conditions
Operating Temperature
0°C ~ 40°C (32°F - 104°F)
Operating Humidity
0% ~ 80% RH
Storage Temperature
-20°C ~ 60°C (-4°F - 140°F)
Regulatory
Compliance
Safety, Environmental
CE, FCC
Enclosure
Size
19” 5RU
Type
Aluminum
Cooling
Convection ventilation (8 ceiling mounted fans)
General
Net Dimensions (W, D, H)
44cm x 26.4cm x 42.1cm (1.4' x 0.8" x 1.3')
W,D,H
Shipping Dimensions (W, D, H)
49cm x 35.5cm x 49cm (1.6' x 1.1' x 1.6')
W,D,H
Net Weight
16.3kg (36lbs) approx.
Shipping Weight
17.2kg (38lbs) approx.
Accessories
Included
OEM Power Cord EU & US C-14 L-180CM
Specifications are subject to change without notice at www.kramerav.com
