Page #43 background imageLoading...
Page #43 background image
Kramer Electronics Ltd.
VW-16 Protocol 3000
41
Protocol 3000 Commands
Function
Description
Syntax
Parameters/
Attributes
Example
#
Protocol handshaking.
Validates the Protocol
3000 connection and gets
the machine number.
Step-in master products
use this command to
identify the availability of a
device.
COMMAND
#<CR>
FEEDBACK
~nn@ok<CR><LF>
#<CR>
BACKUP
Use to backup data to a
USB flash drive.
COMMAND
#BACKUP<CR>
FEEDBACK
~nn@BACKUPOK<CR><LF>
Backup data to USB
flash drive
#BACKUP <CR>
BEZEL
Set bezel On/Off, H/V
correction.
COMMAND
#BEZELout_index,hv_value,switch,h_value,v_value<CR>
FEEDBACK
~nn@BEZELout_index,hv_value,switch,h_value,v_value<
CR><LF>
out_index Number that indicates the
specific output:
1-N (N= the total number of outputs)
hv_value
0 current H/V value
1 max. H/V value
switch Enable/Disable bezel
correction
0 Off
1 On
h_value Horizonta correction values
v_value Vertical correction values
Set bezel On with H/V
correction:
#BEZEL1,0,1,12,24
<CR>
BEZEL?
Get bezel switch, H/V
correction status.
COMMAND
#BEZEL?out_index<CR>
FEEDBACK
~nn@BEZELout_index,hv_value,switch,h_value,v_value<
CR><LF>
out_index Number that indicates the
specific output:
1-N (N= the total number of outputs)
hv_value
0 current H/V value
1 max. H/V value
switch Enable/Disable bezel
correction
0 Off
1 On
h_value Horizonta correction values
v_value Vertical correction values
Get bezel switch, H/V
correction status:
#BEZEL?1<CR>
BUILD-DATE?
Get device build date.
COMMAND
#BUILD-DATE?<CR>
FEEDBACK
~nn@BUILD-DATEdate,time<CR><LF>
date Format: YYYY/MM/DD where
YYYY = Year
MM = Month
DD = Day
time Format: hh:mm:ss where
hh = hours
mm = minutes
ss = seconds
Get the device build
date:
#BUILD-DATE?<CR>
BRIGHTNESS
Set image brightness for
each output.
Value limits can
vary for different devices.
Value is a property of
input connected to current
output. Changing input
source might cause
changes in this value
(refer to device
definitions).
In devices that enable
showing multiple outputs
on one display each in a
separate window this
command relates only to
the window associated
with the output indicated
in the out-index
parameter.
COMMAND
#BRIGHTNESSout_index,value<CR>
FEEDBACK
~nn@BRIGHTNESSout_index,value<CR><LF>
out_index Number that indicates the
specific output: 1-N (N= the total number
of outputs)
value Brightness value
Set the brightness for
output 1 to 50:
#BRIGHTNESS1,50<C
R>
