Kramer VW-16 User Manual

Kramer Electronics Ltd.
VW-16 – Technical Specifications
37
Default Communication Parameters
RS-232
Baud Rate:
115,200
Data Bits:
8
Stop Bits:
1
Parity:
None
Command Format:
ASCII
Example: (mute video on output 1): #VMUTE 1,1
Y 0 92 1<CR>
Ethernet
To reset the IP settings to the factory reset values go to: Menu->Setup -> Factory Reset-> press Enter to
confirm
IP Address:
192.168.1.39
Subnet mask:
255.255.255.0
Default gateway:
192.168.1.254
TCP Port #:
80
Maximum TCP Ports:
1
Full Factory Reset
OSD
Go to: Menu-> SYSTEM -> FACTORY DEFAULT -> YES press Enter to
confirm.
Default EDID
Monitor
Model name............... VW-16
Manufacturer............. KMR
Plug and Play ID......... KMR060D
Serial number............ 49
Manufacture date......... 2014, ISO week 6
Filter driver............ None
-------------------------
EDID revision............ 1.3
Input signal type........ Digital
Color bit depth.......... Undefined
Display type............. Monochrome/grayscale
Screen size.............. 310 x 170 mm (13.9 in)
Power management......... Standby, Suspend
Extension blocs.......... 1 (CEA/CTA-EXT)
-------------------------
DDC/CI................... n/a
Color characteristics
Default color space...... Non-sRGB
Display gamma............ 2.40
Red chromaticity......... Rx 0.611 - Ry 0.329
Green chromaticity....... Gx 0.313 - Gy 0.559
Blue chromaticity........ Bx 0.148 - By 0.131
White point (default).... Wx 0.320 - Wy 0.336
Additional descriptors... None
Timing characteristics
Horizontal scan range.... 15-136kHz
Vertical scan range...... 23-61Hz
Video bandwidth.......... 600MHz
CVT standard............. Not supported
GTF standard............. Not supported
Additional descriptors... None
Preferred timing......... Yes
Native/preferred timing.. 3840x2160p at 60Hz (16:9)
Modeline............... "3840x2160" 594.000 3840 4016 4104 4400 2160 2168 2178 2250 +hsync +vsync
Detailed timing #1....... 1920x1080p at 60Hz (16:9)
Modeline............... "1920x1080" 148.500 1920 2008 2052 2200 1080 1084 1089 1125 +hsync +vsync
Standard timings supported
640 x 480p at 60Hz - IBM VGA
640 x 480p at 72Hz - VESA
640 x 480p at 75Hz - VESA
