Kramer VW-16 User Manual

Kramer Electronics Ltd.
VW-16 – Protocol 3000
43
Function
Description
Syntax
Parameters/
Attributes
Example
CPEDID
Copy EDID data from the
output to the input
EEPROM.
Destination bitmap
size depends on device
properties (for 64 inputs it
is a 64-bit word).
Example: bitmap 0x0013
means inputs 1,2 and 5
are loaded with the new
EDID.
In certain products
Safe_mode is an optional
parameter. See the HELP
command for its
availability.
COMMAND
#CPEDIDedid_io,src_id,edid_io,dest_bitmap<CR>
or
#CPEDIDedid_io,src_id,edid_io,dest_bitmap,safe_mode
<CR>
FEEDBACK
~nn@CPEDIDedid_io,src_id,edid_io,dest_bitmap<CR><LF
>
~nn@CPEDIDedid_io,src_id,edid_io,dest_bitmap,safe_m
ode<CR><LF>
edid_io – EDID source type (usually
output)
0 – Input
1 – Output
2 – Default EDID
3 – Custom EDID
src_id – Number of chosen source
stage
0 – Default EDID source
1 – Output 1
2 – Output 2
edid_io – EDID destination type
(usually input)
0 – Input
1 – Output
2 – Default EDID
3 – Custom EDID
dest_bitmap – Bitmap representing
destination IDs. Format: XXXX…X,
where X is hex digit. The binary form of
every hex digit represents
corresponding destinations.
0 – indicates that EDID data is not
copied to this destination.
1 – indicates that EDID data is copied
to this destination.
safe_mode – Safe mode
0 – device accepts the EDID as is
without trying to adjust
1 – device tries to adjust the EDID
(default value if no parameter is
sent)
Copy the EDID data
from the Output 1 (EDID
source) to the Input:
#CPEDID1,1,0,0x1<
CR>
Copy the EDID data
from the default EDID
source to the Input:
#CPEDID2,0,0,0x1<
CR>
CRDT
Set window size and
position.
COMMAND
#CRDTout_index,left,top,right,bottom<CR>
FEEDBACK
~nn@CRDTout_index,left,top,right,bottom<CR><LF>
out_index – Number that indicates the
specific output:
1-N (N= the total number of outputs)
left – Left coordinate
top – Top coordinate
right – Right coordinate
bottom – Bottom coordinate
Set window 2 size and
position:
#CRDT2,0,0,480,64
0<CR>
CRDT?
Get window size and
position.
COMMAND
#CRDT?out_index<CR>
FEEDBACK
~nn@CRDTout_index,left,top,right,bottom<CR><LF>
out_index – Number that indicates the
specific output:
1-N (N= the total number of outputs)
left – Left coordinate
top – Top coordinate
right – Right coordinate
bottom – Bottom coordinate
Get window 2 size and
position:
#CRDT?2<CR>
DEL
Delete file.
COMMAND
#DELfile_name<CR>
FEEDBACK
~nn@DELfile_name<CR><LF>
file_name – Name of file to delete (file
names are case-sensitive)
Delete the Room1Config
file:
#DELroom1config<C
R>
DIR
List files in device.
COMMAND
#DIR<CR>
FEEDBACK
Multi-line:
~nn@DIR<CR><LF>
file_name TABfile_sizebytes,id:file_id<CR><LF>
TABfree_sizebytes.<CR><LF>
file_name – Name of file
file_size – File size in bytes. A file
can take more space on device memory
file_id – Internal ID for file in file
system
free_size – Free space in bytes in
device file system
#DIR<CR>
DISPLAY?
Get output HPD status.
COMMAND
#DISPLAY?out_index<CR>
FEEDBACK
~nn@DISPLAYout_index,status<CR><LF>
out_index – Number that indicates the
specific output:
1-N (N= the total number of outputs)
status – HPD status according to
signal validation
0 – Signal or sink is not valid
1 – Signal or sink is valid
2 – Sink and EDID is valid
Get the output HPD
status of Output 1:
#DISPLAY?1<CR>
ETH-PORT
Set Ethernet port protocol.
If the port number you
enter is already in use, an
error is returned.
The port number must be
within the following range:
0-(2^16-1).
COMMAND
#ETH-PORTport_type,port_id<CR>
FEEDBACK
~nn@ETH-PORTport_type,port_id<CR><LF>
port_type – TCP/UDP
port_id – TCP/UDP port number
(0 – 65535)
Set the Ethernet port
protocol for TCP to port
12457:
#ETH-PORT0,12457<
CR>
ETH-PORT?
Get Ethernet port
protocol.
COMMAND
#ETH-PORT?port_type<CR>
FEEDBACK
~nn@ETH-PORTport_type,port_id<CR><LF>
port_type – TCP/UDP
0 – TCP
1 – UDP
port_id – TCP / UDP port number (0 –
65535)
Get the Ethernet port
protocol for UDP:
#ETH-PORT?1<CR>
FACTORY
Reset device to factory
default configuration.
This command deletes
all user data from the
device. The deletion can
take some time.
Your device may require
powering off and
powering on for the
changes to take effect.
COMMAND
#FACTORY<CR>
FEEDBACK
~nn@FACTORYok<CR><LF>
Reset the device to
factory default
configuration:
#FACTORY<CR>
