Krone Comprima F - Checking the Retaining Comb for Film Tying

Important Settings for Film Tying
20
Pos: 6.10 /Übersc hriften/Übersc hriften 2/P-T/R /Rückhalte kamm bei Folienbin dung prüfen @ 396\mod_144 6714788786_7 8.docx @ 28 18619 @ 2 @ 1
3.2 Checking the Retaining Comb for Film Tying
Pos: 6.11 /Bei packs/Rundball enpressen/Folienbi ndung/Modulg ruppen Umbau 2015/ZBBP177 7, ZBBP1793: R ückhaltekam m montieren @ 339\mod _1430999054618_7 8.docx @ 25 70386 @ @ 1
ZBBP1777_2
2
Fig.
17
ZBBP1793_1
X
Fig.
18
Pos: 6.12 /BA/Bedi enung /Run dballenpresse/Folie nbindung/R ückhaltekam m prüfen_Text_Folie nbindung_Co mprima @ 39 3\mod_1446 206922502_78. docx @ 28092 96 @ @ 1
The retaining comb (2) is located at front on the machine in the twine box.
• Check whether the dimension x on the spring on right is 20 mm.
• In case of deviation, set the dimension x=20 mm by using the nut.
