10 Parameter list
62 of 88
BoosterControl Advanced
Parameter Description Factory setting Possible settings min. value max. value Read access right Write access right
3-4-1-4-8 Threshold
1 or 2 extra signalling relay contacts for
switching thresholds
- - - - Everybody Service
3-4-1-4-8-1 Threshold 1 ON
Inlet tank level for relay 1 energised in
percent
50 0...199 0 199 Everybody Service
3-4-1-4-8-2 Threshold 1 OFF
Inlet tank level for relay 1 de-energised in
percent
50 0...199 0 199 Everybody Service
3-4-1-4-8-3 Threshold 2 ON
Inlet tank level for relay 2 energised in
percent
40 0...199 0 199 Everybody Service
3-4-1-4-8-4 Threshold 2 OFF
Inlet tank level for relay 2 de-energised in
percent
40 0...199 0 199 Everybody Service
3-4-1-4-9 Supply valve ON/OFF
Position of inflow gate valve for filling inlet
tank
- - - - Everybody Nobody
3-4-1-4-9-1 Level 1 open
Level for opening gate valve to start filling
inlet tank
70 0.. 99 0 99 Everybody Service
3-4-1-4-9-2 Level 1 closed
Level for closing gate valve to stop filling
inlet tank
90 0.. 99 0 99 Everybody Service
3-4-1-4-9-3 Level 1A open
Second level (timer-based) for opening
gate valve to start filling
40 0.. 99 0 99 Everybody Service
3-4-1-4-9-4 Level 1A closed
Second level (timer-based) for closing gate
valve to stop filling
60 0.. 99 0 99 Everybody Service
3-4-1-4-10 Supply valve prop.
Use of a proportional valve to fill inlet tank
- - - - Everybody Nobody
3-4-1-4-10-1 Level setpoint 1
Level in inlet tank at which valve is
completely closed
80 0.. 99 0 99 Everybody Service
3-4-1-4-10-2 Level setpoint 1A
Second level (timer-based) in inlet tank at
which valve is completely closed
40 0.. 99 0 99 Everybody Service
3-4-1-4-10-3 Hysteresis
Setting the hysteresis for fully open valve
15 0.. 99 0 99 Everybody Service
3-4-1-4-10-4 Sample time
Measurement cycle for measuring to
control proportional valve
10 0.. 99 0 99 Everybody Service
