10 Parameter list
BoosterControl Advanced
63 of 88
Parameter Description Factory setting Possible settings min. value max. value Read access right Write access right
3-4-1-4-10-5 Analog output
Configuring the analog output
4-20mA 4-20mA,
0-20mA
- - Everybody Service
3-4-1-5 Auto. Setpoint Redu.
Automatic setpoint reduction in case of
inlet pressure drop
- - - - Everybody Nobody
3-4-1-5-1 ASR function
Automatic setpoint reduction in case of
inlet pressure drop
Off Off,
On
- - Everybody Service
3-4-1-5-2 Switch on point
Re-start point
200 100.. 400 100 400 Everybody Service
3-4-1-5-3 Inlet Set point
Entering the minimum inlet pressure
setpoint
100 0.. 400 0 400 Everybody Service
3-4-1-5-4 Switch off point
Stop point
90 0.. 100 0 100 Everybody Service
3-4-1-5-5 Proportional const.
Proportional constant of PID controller
3 0.. 10 0 10 Everybody Service
3-4-1-5-6 Integral time
Integral constant of PID controller
1 0.. 60 0 60 Everybody Service
3-4-1-5-7 Differential time
Differential constant of PID controller
0 0.. 99 0 99 Everybody Service
3-4-1-5-9 Switch On time
Time to pump start
5 0.. 60 0 60 Service Service
3-4-1-5-10 Switch Off time
Time to pump stop
5 0.. 60 0 60 Service Service
3-4-2 Discharge
Discharge-side parameterisation
- - - - Everybody Service
3-4-2-1 Sensor press. 4 mA
Analog measured value at 4mA,
discharge side
0 -100.. 1000 -100 1000 Everybody Service
3-4-2-2 Sensor press. 20 mA
Analog measured value at 20 mA,
discharge side
1000 0.. 9999 0 9999 Everybody Service
3-4-2-3 Pumps ON sensor fail
Number of pumps started up in the event
of a sensor failure on the discharge side
0 0.. 3 0 3 Everybody Service
3-4-2-4 Max power
Limitation of maximum system power (n x
100%, n = number of pumps)
600 0.. 600 0 600 Everybody Service
3-4-2-5 Max power ext. oper.
Limitation of maximum system power for
operation on emergency power
600 0.. 600 0 600 Everybody Service
