KSB BoosterControl Advanced - Page 64

10 Parameter list
64 of 88
BoosterControl Advanced
Parameter Description Factory setting Possible settings min. value max. value Read access right Write access right
3-4-3 Variable freq. drive
Configuring the frequency inverters
- - - - Everybody Nobody
3-4-3-1 Communication
Configuring the communication protocol for
the frequency inverter
None None,
Analog 4-20 mA,
Analog 0-20 mA,
PumpDrive,
Danfoss VLT 2800,
Danfoss MicroDrive,
Danfoss AquaDrive
- - Everybody Service
3-4-3-2 Proportional const.
Proportional constant of PID controller
3 0.. 100 0 100 Everybody Service
3-4-3-3 Integral time
Integral constant of PID controller
1 0.. 60 0 60 Everybody Service
3-4-3-4 Differential time
Differential constant of PID controller
0 0.. 99,99 0 99,99 Everybody Service
3-4-3-9 VFD Ramp-Up
Configuring the start ramp for frequency
inverters in seconds
3 0,1.. 999 0,1 999 Everybody Service
3-4-3-10 VFD Ramp-Down
Configuring the stop ramp for frequency
inverters in seconds
3 0,1.. 999 0,1 999 Everybody Service
3-4-3-11 VFD min. frequency
Configuring the minimum frequency for
frequency inverters in Hz
30 0.. 50 0 50 Everybody Service
3-4-3-12 VFD max. frequency
Configuring the maximum frequency for
frequency inverters in Hz
50 30.. 140 30 140 Everybody Service
3-4-3-13 P nominal of VFD
Nominal power of frequency inverters
1500 0.. 100000 0 100000 Everybody Service
3-4-3-14 U nominal of VFD
Nominal voltage of frequency inverters
400 0.. 500 0 500 Everybody Service
3-4-3-15 F nominal of VFD
Nominal frequency of frequency inverters
50 50.. 50 50 50 Everybody Service
3-4-3-16 I nominal of VFD
Nominal amperage of frequency inverters
4 0.. 450 0 450 Everybody Service
3-4-3-17 RPM nominal of VFD
Nominal speed of frequency inverters
2880 0.. 10000 0 10000 Everybody Service
3-4-3-20 Motor Speed Unit
Motor speed unit
U/min Rpm,
Hz
- - Everybody Service
3-4-3-21 Digital I/P 33 func.
Selecting the digital input
No function No function,
Coasting stop inv.
- - Everybody Service
3-4-3-22 Digital I/P 29 func.
Selecting the digital input
No function No function,
Jog function,
Jog function
- - Everybody Service
