KTM 1290 SUPER DUKE R 2021 User Manual

19 SERVICE WORK ON THE ENGINE
150
S03958-10
–
Mount and tighten oil drain plugs
1
with magnets, O-rings,
and oil screens.
Guideline
Oil drain plug M20x1.5 20 Nm (14.8 lbf ft)
S03962-10
–
Have the entire filling quantity available.
Engine oil
Ambient
temperature: ≥ 0 °C
(≥ 32 °F)
3.50 l
(3.7 qt.)
Engine oil
(SAE 10W/50)
( p. 175)
Engine oil
Ambient
temperature: < 0 °C
(< 32 °F)
Engine oil (SAE
5W/40) ( p. 176)
– Add the oil quantity in two steps.
–
Remove filler plug
5
with the O-ring, and fill up with the first
partial quantity.
Engine oil (1st par-
tial quantity) approx.
Ambient
temperature: ≥ 0 °C
(≥ 32 °F)
3.0 l (3.2 qt.) Engine oil
(SAE 10W/50)
( p. 175)
Engine oil (1st par-
tial quantity) approx.
Ambient
temperature: < 0 °C
(< 32 °F)
Engine oil (SAE
5W/40) ( p. 176)
–
Mount filler plug
5
with the O-ring.
Danger
Danger of poisoning Exhaust gases are toxic and inhal-
ing them may result in unconsciousness and death.
– Always make sure there is sufficient ventilation
when running the engine.
– Use effective exhaust extraction when starting or
running the engine in an enclosed space.
– Start the engine and check for leaks.
– Switch off the engine.

KTM 1290 SUPER DUKE R 2021 Specifications

General

Displacement	1301 cc
Transmission	6-speed
Rear Suspension	WP APEX monoshock, fully adjustable
Seat Height	835 mm
Fuel Tank Capacity	16 liters
Dry Weight	189 kg
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.5:1
Fuel System	Electronic fuel injection
Lubrication	Forced oil lubrication with 3 oil pumps
Wheelbase	1482 mm
Traction Control	MTC (Motorcycle Traction Control), lean-angle sensitive
Engine Type	V-Twin, 4-stroke
Power	180 hp
Torque	140 Nm @ 8000 rpm
Frame	Chromium-Molybdenum steel frame, powder coated
Front Suspension	WP APEX 48
Front Brake	320 mm discs
Rear Brake	Brembo two-piston caliper, 240 mm disc
Clutch	PASC slipper clutch, hydraulically actuated
ABS	Bosch 9.1 MP (incl. Cornering ABS and Supermoto mode)
