KTM 300 EXC - 11.15 Adjusting the Handlebar Position

11 TUNING THE CHASSIS
54
Info
Turn clockwise to increase the damping; turn counter-
clockwise to reduce damping when the shock absorber
rebounds.
11.14 Handlebar position
M00993-10
On the upper triple clamp, there are 2 holes at a distance of
A
to
each other.
Hole distance A 15 mm (0.59 in)
The holes on the handlebar support are placed at a distance of
B
from the center.
Hole distance B 3.5 mm (0.138 in)
The handlebar can be mounted in four different positions. This
allows the handlebar to be mounted in the most comfortable posi-
tion for the rider.
11.15 Adjusting the handlebar position
Warning
Danger of accidents A repaired handlebar poses a safety risk.
If the handlebar is bent or straightened, the material becomes fatigued. The handlebar may break as a
result.
– Change the handlebar if the handlebar is damaged or bent.
