TECHNICAL DATA 22
141
Weight of rider: 65 … 75 kg (143 … 165 lb.) 3.8 N/mm (21.7 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 4.0 N/mm (22.8 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 4.2 N/mm (24 lb/in)
Fork length 928 mm (36.54 in)
Fork oil per fork leg 625 ± 10 ml (21.13
± 0.34 fl. oz.)
Fork oil (SAE 4) (48601166S1)
( p. 145)
22.9 Shock absorber
Shock absorber article number 12.18.7T.63
Shock absorber WP XPLOR 5746
Low-speed compression damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
High-speed compression damping
Comfort 2.5 turns
Standard 2 turns
Sport 1 turn
Rebound damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Spring preload 10 mm (0.39 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 57 … 63 N/mm (325 … 360 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 60 … 66 N/mm (343 … 377 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 63 … 69 N/mm (360 … 394 lb/in)
Spring length 225 mm (8.86 in)
Gas pressure 10 bar (145 psi)
Static sag 37 mm (1.46 in)
Riding sag 110 mm (4.33 in)
Fitted length 415 mm (16.34 in)
Shock absorber fluid ( p. 145) SAE 2.5
22.10 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, seat fixing EJOT EJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, emergency OFF switch M4 0.4 Nm (0.3 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple, front wheel M4.5 5 Nm (3.7 lbf ft)
Spoke nipple, rear wheel M4.5 5 Nm (3.7 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
