KTM RC 200 - Page 104

12 SERVICE WORK ON THE CHASSIS 102
G00963-10
– Position the side cover.
–
Mount and tighten screws

.
Guideline
Screw, side cover M6 7 Nm (5.2 lbf ft)
–
Push on the side cover in area

.
The holding lug engages in the drilled hole on the front spoiler.
–
Mount and tighten screws

.
Guideline
Screw, side cover on front mask M6 6 Nm (4.4 lbf ft)
L02198-10
–
Mount expanding rivet

.
