7 COMBINATION INSTRUMENT 52
7.18 Distance menu 1 TRIP 1
401304-01
Condition
Alternative 1
The ignition is on.
The motorcycle is stationary.
Alternative 2
The ignition is on.
The motorcycle is moving.
Press the MODE button briefly and repeatedly until TRIP 1 appears on the display.
TRIP 1shows the distance since the last reset, such as between two refueling stops. TRIP 1
is always running and counts up to 999.9.
Press the SET button
for 5 - 10 seconds.
Display of TRIP 1 is reset
Press the MODE but-
ton.
Next display mode on the display
7.19 Distance menu 2 TRIP 2
401305-01
Condition
Alternative 1
The ignition is on.
The motorcycle is stationary.
Alternative 2
The ignition is on.
The motorcycle is moving.
Press the MODE button briefly and repeatedly until TRIP 2 appears on the display.
TRIP 2shows the distance since the last reset, such as between two refueling stops. TRIP 2
is always running and counts up to 999.9.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM RC 200 and is the answer not in the manual?

KTM RC 200 Specifications

General IconGeneral
Displacement199.5 cc
Transmission6-speed
Fuel SystemElectronic Fuel Injection
Rear SuspensionWP APEX Monoshock
Bore x Stroke72 mm x 49 mm
Compression Ratio11.5:1
Max Power25 PS @ 10000 rpm
Max Torque19.2 Nm @ 8000 rpm
Front Brake300 mm disc
Rear Brake230 mm disc
Fuel Tank Capacity13.7 liters
Kerb Weight160 kg
Front SuspensionWP APEX 43 mm Upside Down
ABSDual Channel
Tyre Front110/70-17
Tyre Rear150/60-R17
Ground Clearance157 mm
Engine TypeSingle Cylinder, Liquid Cooled
