KTM RC 200 User Manual

6 CONTROLS 24
6.5 Light switch
L02113-11
The light switch

is fitted on the left side of the handlebar.
Possible states
Low beam on – Light switch is turned downward. In this position, the low
beam and tail light are switched on.
High beam on – The light switch is turned upwards. In this position, the
low beam, the high beam and the tail light are switched on.
6.6 High beam flasher button
L02113-12
The high beam flasher button

is fitted on the left side of the handlebar.
Possible states
• High beam flasher button in neutral position
• High beam flasher button pressed – In this position, the headlight flasher (high beam)
is actuated.

KTM RC 200 Specifications

General

Displacement	199.5 cc
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP APEX Monoshock
Bore x Stroke	72 mm x 49 mm
Compression Ratio	11.5:1
Max Power	25 PS @ 10000 rpm
Max Torque	19.2 Nm @ 8000 rpm
Front Brake	300 mm disc
Rear Brake	230 mm disc
Fuel Tank Capacity	13.7 liters
Kerb Weight	160 kg
Front Suspension	WP APEX 43 mm Upside Down
ABS	Dual Channel
Tyre Front	110/70-17
Tyre Rear	150/60-R17
Ground Clearance	157 mm
Engine Type	Single Cylinder, Liquid Cooled
