23 TECHNICAL DATA 183

Spark plug BOSCH Super R6 VR 5 NEW

Spark plug electrode gap 1 mm (0.04 in)

Cooling Water cooling, permanent circulation of coolant by water pump

Idle speed 1,450… 1,550 rpm

Starting aid Electric starter

23.2 Engine tightening torques

Oil nozzle M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, engine vent plate M5 7 Nm (5.2 lbf ft) Loctite

243™

Screw, oil filter cover M5 8 Nm (5.9 lbf ft) –

Screw, retaining bracket M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, retaining bracket, stator cable M5 8 Nm (5.9 lbf ft) Loctite

243™

Screw, stator M5 8 Nm (5.9 lbf ft) Loctite

243™

Cylinder head screw M6 12 Nm (8.9 lbf ft) –

Nut, water pump impeller M6 10 Nm (7.4 lbf ft) Loctite

243™

Plug, water pump drain hole M6 8 Nm (5.9 lbf ft) –

Screw, alternator cover M6 12 Nm (8.9 lbf ft) –

Screw, bearing retainer M6 12 Nm (8.9 lbf ft) Loctite

243™

Screw, camshaft bearing bridge M6 11 Nm (8.1 lbf ft) –

Screw, chain securing guide M6 11 Nm (8.1 lbf ft) Loctite

243™

Screw, clutch cover M6 12 Nm (8.9 lbf ft) –

Screw, engine case M6x40 12 Nm (8.9 lbf ft) –

Screw, engine case M6x60 12 Nm (8.9 lbf ft) Loctite

243™

Screw, freewheel gear retaining bracket M6 12 Nm (8.9 lbf ft) Loctite

243™

Questions and Answers:

Need help?

Do you have a question about the KTM RC 200 and is the answer not in the manual?

KTM RC 200 Specifications

General

Displacement	199.5 cc
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP APEX Monoshock
Bore x Stroke	72 mm x 49 mm
Compression Ratio	11.5:1
Max Power	25 PS @ 10000 rpm
Max Torque	19.2 Nm @ 8000 rpm
Front Brake	300 mm disc
Rear Brake	230 mm disc
Fuel Tank Capacity	13.7 liters
Kerb Weight	160 kg
Front Suspension	WP APEX 43 mm Upside Down
ABS	Dual Channel
Tyre Front	110/70-17
Tyre Rear	150/60-R17
Ground Clearance	157 mm
Engine Type	Single Cylinder, Liquid Cooled
