14 WHEELS, TIRES 117
14.1 Removing the front wheel
Preparatory work
Raise the motorcycle with the rear wheel stand. ( p. 78)
Raise the motorcycle with the front wheel stand. ( p. 79)
L02193-10
Main work
(RC 200)
Loosen screw
and screws
.
Unscrew screw
about 6 turns and press your hand on the screw to push the
wheel spindle out of the axle clamp. Remove screw
.
Warning
Danger of accidentsReduced braking effect caused by damaged brake
discs.
Always lay the wheel down in such a way that the brake discs are not
damaged.
Holding the front wheel, withdraw the wheel spindle. Take the front wheel out of the
fork.
Info
Do not pull the hand brake lever when the front wheel is removed.
