7 COMBINATION INSTRUMENT 41
7.6 Display
401685-11
The speed
is shown in kilometers per hour km/h or in miles per hour mph.
The tachometer
shows the engine speed in revolutions per minute.
The gear display
shows the engaged gear.
The coolant temperature appears in segment
.
The time appears in segment
.
The filling level in the fuel tank is displaced in segment
.
The info display
shows additional information.
Info
The time must be reset after the battery was disconnected or the fuse was removed.
The intensity of the LED display depends on the ambient brightness.
