18 SERVICE WORK ON THE ENGINE 164
0
0
11
401955-10
Main work
–
Remove the oil filler plug

with the O-ring from the clutch cover and fill up with
engine oil.
Engine oil (SAE 15W/50) ( p. 195)
Engine oil (SAE 10W/40) ( p. 196)
Info
For optimal performance of the engine oil, do not mix different types of engine
oil.
If appropriate, change the engine oil.
– Install and tighten the oil filler plug with the O-ring.
Danger
Danger of poisoning Exhaust gases are toxic and inhaling them may result in
unconsciousness and/or death.
– When running the engine, always make sure there is sufficient ventilation,
and do not start or run the engine in an enclosed space without an effective
exhaust extraction system.
– Start the engine and check that it is oil-tight.
Finishing work
– Check the engine oil level. ( p. 160)

KTM RC 200 Specifications

General

Displacement	199.5 cc
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP APEX Monoshock
Bore x Stroke	72 mm x 49 mm
Compression Ratio	11.5:1
Max Power	25 PS @ 10000 rpm
Max Torque	19.2 Nm @ 8000 rpm
Front Brake	300 mm disc
Rear Brake	230 mm disc
Fuel Tank Capacity	13.7 liters
Kerb Weight	160 kg
Front Suspension	WP APEX 43 mm Upside Down
ABS	Dual Channel
Tyre Front	110/70-17
Tyre Rear	150/60-R17
Ground Clearance	157 mm
Engine Type	Single Cylinder, Liquid Cooled
