23 TECHNICAL DATA 179

Fitted length 304 mm (11.97 in)

23.9 Chassis tightening torques

Exhaust clamp - 19 Nm (14 lbf ft) –

Screw, chain guard EJOT PT

K60x30 4 Nm (3 lbf ft) –

Remaining nuts, chassis M4 3 Nm (2.2 lbf ft) –

Remaining screws, chassis M4 4 Nm (3 lbf ft) –

Screw, EFI control unit M4 3 Nm (2.2 lbf ft) –

Nut, reflector on retaining plate M5 5 Nm (3.7 lbf ft) –

Nut, retaining plate on license plate

holder

M5 4 Nm (3 lbf ft) –

Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, ABS hose clamp M5 5 Nm (3.7 lbf ft) –

Screw, anti-rotation lock, handlebar stub M5 4 Nm (3 lbf ft) –

Screw, battery compartment M5 4 Nm (3 lbf ft) –

Screw, chain guard M5 7 Nm (5.2 lbf ft) Loctite

204™

Screw, cover in front of battery compart-

ment

M5 4 Nm (3 lbf ft) –

Screw, fuel pump M5 5 Nm (3.7 lbf ft) –

Screw, fuel tank cover M5 4 Nm (3 lbf ft) –

Screw, rollover sensor M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, side stand switch M5 5 Nm (3.7 lbf ft) Loctite

243™

Screw, tail end lower part M5 4 Nm (3 lbf ft) –

Cap bolt, footrest M6 9 Nm (6.6 lbf ft) –

Questions and Answers:

Need help?

Do you have a question about the KTM RC 390 and is the answer not in the manual?

KTM RC 390 Specifications

General

Displacement	373.2 cc
Max Torque	37 Nm @ 7000 rpm
Transmission	6-speed
Cooling System	Liquid Cooled
Front Suspension	WP APEX 43
Rear Suspension	WP APEX Monoshock
Rear Brake	230 mm disc, single-piston floating caliper
Fuel Tank Capacity	13.7 liters
Seat Height	824 mm
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Frame	Steel Trellis Frame, Powder Coated
Engine Type	Single-cylinder, 4-stroke
Max Power	43.5 PS @ 9000 rpm
Fuel System	Electronic Fuel Injection
Front Brake	320 mm disc, 4-piston radial caliper
ABS	Dual Channel ABS
Dry Weight	172 kg
Front Tire	110/70 R17
Rear Tire	150/60 R17
Ground Clearance	158 mm
