KTM RC 390 User Manual

7 COMBINATION INSTRUMENT 55
Info
The MODE button increases the value.
The SET button decreases the value.
– Do not activate the two buttons for approx. 15 seconds.
The display RPM 1 goes out and the set speed is stored.
7.23 Adjusting the shift speed RPM 2
Condition
The ignition is on.
The motorcycle is stationary.
401308-01
– Press the MODE button briefly and repeatedly until TRIP 2 appears on the display.
– Press the SET button for 5 - 10 seconds.
The display RPM 2 appears.
Info
The engine speed can be set at intervals of 50.
RPM 2 is the engine speed above which the shift warning light lights up con-
stantly.
The speed RPM 2 must always be higher than the speed RPM 1.
– Set the speed with the MODE and SET buttons.
Info
The MODE button increases the value.
The SET button decreases the value.
– Do not activate the two buttons for approx. 15 seconds.
The display RPM 2 goes out and the set speed is stored.

KTM RC 390 Specifications

General

Displacement	373.2 cc
Max Torque	37 Nm @ 7000 rpm
Transmission	6-speed
Cooling System	Liquid Cooled
Front Suspension	WP APEX 43
Rear Suspension	WP APEX Monoshock
Rear Brake	230 mm disc, single-piston floating caliper
Fuel Tank Capacity	13.7 liters
Seat Height	824 mm
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Frame	Steel Trellis Frame, Powder Coated
Engine Type	Single-cylinder, 4-stroke
Max Power	43.5 PS @ 9000 rpm
Fuel System	Electronic Fuel Injection
Front Brake	320 mm disc, 4-piston radial caliper
ABS	Dual Channel ABS
Dry Weight	172 kg
Front Tire	110/70 R17
Rear Tire	150/60 R17
Ground Clearance	158 mm
