7 COMBINATION INSTRUMENT 35
7.2 Activation and test
401686-01
Activation
The combination instrument is activated when the ignition is switched on.
Test
The segments of the tachometer and the gear display light up and switch off in sequence.
The speed display counts from 0 to 199 and back.
The remaining display segments outside the info display light up briefly.
The READY TO RACE >> logo appears on the info display.
The display then changes to the last selected mode.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM RC 390 and is the answer not in the manual?

KTM RC 390 Specifications

General IconGeneral
Displacement373.2 cc
Max Torque37 Nm @ 7000 rpm
Transmission6-speed
Cooling SystemLiquid Cooled
Front SuspensionWP APEX 43
Rear SuspensionWP APEX Monoshock
Rear Brake230 mm disc, single-piston floating caliper
Fuel Tank Capacity13.7 liters
Seat Height824 mm
Bore x Stroke89 mm x 60 mm
Compression Ratio12.6:1
FrameSteel Trellis Frame, Powder Coated
Engine TypeSingle-cylinder, 4-stroke
Max Power43.5 PS @ 9000 rpm
Fuel SystemElectronic Fuel Injection
Front Brake320 mm disc, 4-piston radial caliper
ABSDual Channel ABS
Dry Weight172 kg
Front Tire110/70 R17
Rear Tire150/60 R17
Ground Clearance158 mm
