KTM RC 390 User Manual

7 COMBINATION INSTRUMENT 52
7.18 Distance menu 1 TRIP 1
401304-01
Condition
Alternative 1
• The ignition is on.
• The motorcycle is stationary.
Alternative 2
• The ignition is on.
• The motorcycle is moving.
– Press the MODE button briefly and repeatedly until TRIP 1 appears on the display.
TRIP 1shows the distance since the last reset, such as between two refueling stops. TRIP 1
is always running and counts up to 999.9.
Press the SET button
for 5 - 10 seconds.
Display of TRIP 1 is reset
Press the MODE but-
ton.
Next display mode on the display
7.19 Distance menu 2 TRIP 2
401305-01
Condition
Alternative 1
• The ignition is on.
• The motorcycle is stationary.
Alternative 2
• The ignition is on.
• The motorcycle is moving.
– Press the MODE button briefly and repeatedly until TRIP 2 appears on the display.
TRIP 2shows the distance since the last reset, such as between two refueling stops. TRIP 2
is always running and counts up to 999.9.

KTM RC 390 Specifications

General

Displacement	373.2 cc
Max Torque	37 Nm @ 7000 rpm
Transmission	6-speed
Cooling System	Liquid Cooled
Front Suspension	WP APEX 43
Rear Suspension	WP APEX Monoshock
Rear Brake	230 mm disc, single-piston floating caliper
Fuel Tank Capacity	13.7 liters
Seat Height	824 mm
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Frame	Steel Trellis Frame, Powder Coated
Engine Type	Single-cylinder, 4-stroke
Max Power	43.5 PS @ 9000 rpm
Fuel System	Electronic Fuel Injection
Front Brake	320 mm disc, 4-piston radial caliper
ABS	Dual Channel ABS
Dry Weight	172 kg
Front Tire	110/70 R17
Rear Tire	150/60 R17
Ground Clearance	158 mm
