KTM RC 390 User Manual

7 COMBINATION INSTRUMENT 41
7.6 Display
401685-11
The speed

is shown in kilometers per hour km/h or in miles per hour mph.
The tachometer

shows the engine speed in revolutions per minute.
The gear display

shows the engaged gear.
The coolant temperature appears in segment

.
The time appears in segment

.
The filling level in the fuel tank is displaced in segment

.
The info display

shows additional information.
Info
The time must be reset after the battery was disconnected or the fuse was removed.
The intensity of the LED display depends on the ambient brightness.

KTM RC 390 Specifications

General

Displacement	373.2 cc
Max Torque	37 Nm @ 7000 rpm
Transmission	6-speed
Cooling System	Liquid Cooled
Front Suspension	WP APEX 43
Rear Suspension	WP APEX Monoshock
Rear Brake	230 mm disc, single-piston floating caliper
Fuel Tank Capacity	13.7 liters
Seat Height	824 mm
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Frame	Steel Trellis Frame, Powder Coated
Engine Type	Single-cylinder, 4-stroke
Max Power	43.5 PS @ 9000 rpm
Fuel System	Electronic Fuel Injection
Front Brake	320 mm disc, 4-piston radial caliper
ABS	Dual Channel ABS
Dry Weight	172 kg
Front Tire	110/70 R17
Rear Tire	150/60 R17
Ground Clearance	158 mm
