UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and controls.
The symbols are shown below with an indication of their meaning.
B General
Safety Alert Symbol
Master System Warning
Fast
Slow
Creep
Read Operator's Manual
Lock
ON (Engaged)
OFF (Disengaged)
Service
B Engine-related
Diesel Fuel
Hourmeter/Elapsed Operating Hours
Engine Coolant-Temperature
Engine Intake/Combustion Air-Filter
Engine Oil-Pressure
Water Separator
Engine-Warning
Engine-Rotational Speed
Engine-Rev Limiter
Engine-Over Speed
Engine-RPM Memory A
Engine-RPM Adjuster
Engine-RPM Increase
Engine-Run
Engine-Start
Engine-Stop
Electrical Power-accessories
Diesel Preheat/Glow Plugs
(Low Temperature Start Aid)
Regeneration
Regeneration inhibit
Regeneration (Switch)
Parked Regeneration
DEF/AdBlue®-Level
DEF/AdBlue®-Low Level
DEF/AdBlue®-Poor Quality
DEF/AdBlue®-Trouble
DEF/AdBlue®-Thawing
B Vehicle body-related
Travel Direction-Forward
Travel Direction-Rearward
Travel Direction
4-Wheel Drive-On
4-Wheel Drive-On
4-Wheel Drive-Automatic
Headland Management System
Cruise Control
To Next Page
