51INTELLIPANEL(TM) CONTROL
BSetting the Engine/Transmission (Power
Shift)
Various settings of the automatic power shift transmission can be made and checked.
Further, the engine rev-limiter, engine rpm memory and other settings may be also set.
C Setting the traveling speed gear in the road mode
Touch the road mode setting switch (6) in the above
figure, and the "road mode" traveling speed gear setting
screen shows up.
1. Referring to the traveling speed chart, determine
maximum and minimum traveling speeds.
2. Setting the maximum speed gear shift
Using the high-speed setting switch (5), preset the
desired traveling speed. (The high-speed slider moves
to the set position.)
3. Setting the minimum speed gear shift
Using the low-speed setting switch (6), preset the
desired traveling speed. (The low-speed slider moves
to the set position.)
4. The automatic gear shift is carried on within the
displayed traveling speed gear shifts (1).
5. Touch the switch (2), and the setting is completed and
the previous screen reappears.
Power Shift Transmission [Premium model]
(1) Engine RPM memory (A/B) indicator
(2) Auto shift mode (Road/Field)
indicator
(3) Shuttle lever indicator
(4) Auto shift range indicator for
road mode
(5) Field mode setting switch
(6) Road mode setting switch
(7) Engine RPM memory (A) switch
(8) Engine RPM memory (B) switch
(9) Plus (+) switch
(10) Minus (-) switch
(11) Engine RPM memory (B) control
(12) Engine RPM memory (A) control
(13) Rev-limiter control
(14) Auto shift sensitivity control
(15) Engine rpm
(1) Selected traveling speed gear shift
(2) Previous screen resume switch
(3) Low-speed slider
(4) High-speed slider
(5) High-speed setting switch
(6) Low-speed setting switch
(7) Main gear shift section
(8) Range gear shift section
